Engineering Documents

Do you want to view city engineering documents?

The City of Orlando provides resources related to engineering standards and wastewater details.

Review the 5th Edition of the Engineering Standards Manual for current information.

As-Built Surveys

(show below)

As-Built Surveys

The City of Orlando Survey Section is responsible for reviewing, rejecting and accepting of any private development or public improvement project as-built survey as it relates to acceptance according the City of Orlando’s Engineering Standards Manual, Chapter 5 Survey Standards and specifically Section 5.03.

Section 5.03 As-Built Survey Requirements

Definition of As-Built Survey as defined in 5J-17.050 of the Florida Administrative Code: a survey performed to obtain horizontal and/or vertical dimensional data so that constructed improvements may be located and delineated.

Wastewater Details

(show below)

FEMA Elevation Certificates

(show below)

Use these tools to find FEMA elevation certificates. Elevation certificates show a building's height in relation to expected flood levels. These certificates are often used for flood insurance purposes and to make sure buildings follow local flood guidelines.

If you need to find out whether your property is in a flood zone, review the resources on Floodplain and Flooding Information.
